BETO S-LINE 225 L DIRECT ceiling / suspended system;BETO S-LINE 225 L DIRECT / INDIRECT POWER suspended system

BETO s-line 225 L direct / indirect power

suspended system

074-7231537B

Quickinfo

3000 K
CRI ≥ 80 / 3 SDCM
UGR < 13 / 65° ≤ 1,500 cd/m²
2,270 lm/↑ 3,960 lm
118 lm/W
L90 / 50000 h
DALI-2
Reflector
IP20 / PC1 220-240V

Colour

Reflector

General

  • Ceiling
  • Suspended
  • white
  • Reflector dark chrome
  • RAL9010 1
  • IP20
  • indirect 3960 lm
  • direct 2270 lm
  • total 6230 lm

LED

  • 3000 K
  • CRI ≥ 80
  • L90 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • MR 0.56
  • MDER 0.51

Optical

  • Reflector
  • symmetric
  • UGR < 13
  • ≥65° <1500 cd/m²
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • system 53 W
  • PC1 220-240V
  • system 118 lm/W3
  • 2 DALI Addr.

Physical

  • length 1641 mm
  • width 265 mm
  • height 42 mm
  • centerline radius 400 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
C10
C13
C16
C20

Number of Fixtures

15
20
25
31
26
33
42
52
1 RAL code 2 Value of containing product at full load (undimmed) 3 incl. optical losses and the efficiency of the operating device (converter)

Luminaire housing made of extruded aluminium profile; extremely slim design (only 42 x 42 mm) S-shaped; converter integrated into luminaire housing; no visible screws; angular design; for lighting systems; surface white powder coated; for suspended mounting (1500 mm cable suspension as an accessory); with integrated toolless suspension height adjustment on the luminaire; spring clip attachment to the luminaire; extruded profile for improved thermal management; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high gloss reflector with faceted design; Reflector dark chrome; UGR ≤ 13; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 1500 cd/m²; direct/indirect illumination characteristic; indirect light component with integrated PC boards and high quality lens system for maximum, homogeneous ceiling illumination, separately controllable; degree of protection IP20; PC1 220-240V; internal wiring in light halogen free; incl. DALI-2 converter; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
