BETO ceiling / suspended system;BETO LINEAR DIRECT ceiling / suspended system

BETO linear direct

ceiling / suspended system

074-6009578R

Quickinfo

3000 K
CRI ≥ 80 / 3 SDCM
UGR < 19 / 65° ≤ 1,500 cd/m²
141 lm/W
L90 / 50000 h
DALI-2 sensor
Reflector
IP20 / PC1 220-240V

Colour

Reflector

General

  • Ceiling
  • Suspended
  • black
  • Reflector chrome
  • RAL9005 1
  • IP20
  • 6360 lm

LED

  • 3000 K
  • CRI ≥ 80
  • L90 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • MR 0.56
  • MDER 0.51

Optical

  • Reflector
  • symmetric
  • UGR < 19
  • ≥65° <1500 cd/m²

Electrical

  • DALI-2 sensor
  • system 45 W
  • PC1 220-240V
  • system 141 lm/W2
  • 2 DALI Addr.

Physical

  • length 3400 mm
  • width 42 mm
  • height 42 mm
  • 5 kg

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
B25
C10
C13
C16
C20
C25

Number of Fixtures

15
20
25
31
39
26
33
42
52
65
1 RAL code 2 incl. optical losses and the efficiency of the operating device (converter)

Luminaire housing made of extruded aluminium profile; extremely slim design (only 42 x 42 mm) linear; converter integrated into luminaire housing; no visible screws; angular design; for lighting systems; surface black powder coated; for ceiling surface mounting or suspended mounting (1500 mm cable suspension as an accessory); with integrated toolless suspension height adjustment on the luminaire; spring clip attachment to the luminaire; extruded profile for improved thermal management; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high gloss reflector with faceted design; Reflector chrome; UGR ≤ 19; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 1500 cd/m²; degree of protection IP20; PC1 220-240V; internal wiring in light halogen free; incl. DALI-2 converter; luminaire with integrated DALI-2 infrared presence and brightness sensor (DALI-2 controller required); automatic light control of luminaire to individually adjustable brightness; variable automatic shutdown; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Download all
lightDistribution
mainDrawing
