SPIO 60 adjustable trimless

SPIO 60 adjustable

trimless

048-1520417F 048-1598107 002-90787

Quickinfo

2700 K
CRI ≥ 90 / 3 SDCM
UGR < 10
33 lm/W, inset 38 lm/W
L85 / 50000 h
non DIM
IP20

Colour

Mounting set

General

  • Ceiling
  • Recessed
  • tilt max 30°
  • rotation 360°
  • white
  • Mounting set traffic white
  • RAL9016 1
  • IP20
  • 455 lm

LED

  • 2700 K
  • CRI ≥ 90
  • L85 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • Rg: 104
  • Rf: 88
  • R{1-15}: 89
  • MR 0.5
  • MDER 0.46

Optical

  • flood
  • beam angle 34°
  • UGR < 10
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • non DIM
  • 220-240 V
  • system 14.0 W
  • inset 11.9 W
  • 12 Vf
  • 1050 mA
  • PC2
  • system 33 lm/W3
  • inset 38 lm/W3

Physical

  • trimless
  • diameter 105 mm
  • height 68 mm
  • 0.3 kg

Cutout

  • diameter 106 mm
  • min. ceiling thickness 12.5 mm
  • max. ceiling thickness 25 mm
  • recessed depth 100 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
B25
C10
C13
C16
C20
C25

Number of Fixtures

17
21
27
33
42
28
36
45
56
70
1 RAL code 2 Value of containing product at full load (undimmed) 3 incl. optical losses and the efficiency of the operating device (converter)

Round recessed spotlight in die-cast aluminium; surface white powder coated; installation without tools in mounting set with magnetic attachment; for trimless installation in plasterboard ceilings, specially designed trim with grooves for better adhesion of smoothing compound; suitable for ceiling thickness of 12.5/15/25 mm; paintable cover; shadow joint between cover and mounting set optionally fillable; 360° rotatable and 30° tiltable; passive cooling of the LEDs through improved heat sink geometry; light colour 2700 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; incl. high quality lens system; precise radiation characteristic with 34° beam; no multiple shadows; uncluttered ceiling look through recessed lighting level; reduced light-emitting surface (only ø 10 mm); degree of protection IP20; PC2; incl. converter, non dimmable; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Certificates

Download all
lightDistribution
mainDrawing
