SPIO 20 downlight
trim
048-1610417F 002-90783
Quickinfo
2700 KCRI ≥ 90 / 3 SDCM
UGR < 10
33 lm/W, inset 44 lm/W
L85 / 50000 h
non DIM
IP20
Colour
General
- Ceiling
- Recessed
- rotation 360°
- white
- RAL9016 1
- IP20
- 289 lm
LED
- 2700 K
- CRI ≥ 90
- L85 / 50000 h
- initial MacAdam ≤ 3 SDCM
- Rg: 104
- Rf: 88
- R{1-15}: 89
- MR 0.5
- MDER 0.46
Optical
- flood
- beam angle 34°
- UGR < 10
- ≤ 1.0 2
- SVM ≤ 0.4 2
Electrical
- non DIM
- system 8.7 W
- inset 6.5 W
- 12 Vf
- 600 mA
- PC2 220-240V
- system 33 lm/W3
- inset 44 lm/W4
Physical
- trim
- diameter 35 mm
- height 66 mm
Cutout
- diameter 26 mm
- min. ceiling thickness 2 mm
- max. ceiling thickness 25 mm
- recessed depth 80 mm
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Round recessed spotlight in aluminium; surface white powder coated; with trim; suitable for ceiling thickness of 2-25 mm; installation without tools using snap spring closure; passive cooling of the LEDs through improved heat sink geometry; light colour 2700 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; incl. high quality lens system; precise radiation characteristic with 34° beam; no multiple shadows; uncluttered ceiling look through recessed lighting level; reduced light-emitting surface (only ø 10 mm); degree of protection IP20; PC2 220-240V; incl. converter, non dimmable; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
