SASSO 60 square wallwasher
ceiling
048-36105317A
Quickinfo
3000 KCRI ≥ 90 / 3 SDCM
81 lm/W, inset 96 lm/W
L80 / 50000 h
DALI-2
IP20
Colour
Inner colour
General
- Ceiling
- Surface
- black
- Inner colour white
- RAL9005/white 1
- IP20
- 789 lm
LED
- 3000 K
- CRI ≥ 90
- L80 / 50000 h
- initial MacAdam ≤ 3 SDCM
- Rg: 97
- Rf: 91
- R{1-15}: 89
- MR 0.6
- MDER 0.54
Optical
- wallwasher
- ≤ 1.0 2
- SVM ≤ 0.4 2
Electrical
- DALI-2
- system 9.7 W
- PC1 220-240V
- system 81 lm/W3
- inset 96 lm/W4
Physical
- length 72 mm
- width 72 mm
- height 108 mm
- 0.5 kg
Circuit Breaker Types
Automatic Circuit Breaker Type
Number of Fixtures
Square ceiling mounted spotlight made of aluminium; surface black (housing/light inset); luminaire housing can be attached to mounting plate without tools by interlock; passive cooling of the LEDs through improved heat sink geometry; no multiple shadows; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; with specially computed, asymmetrical reflector for homogeneous lighting intensity; high quality reflector with micro-faceted, aluminum-vaporised surface; degree of protection IP20; PC1 220-240V; incl. DALI-2 converter; flicker-free visual comfort through analogue current control (minimum value 1%); converter integrated into spotlight head; luminaire for through wiring; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
