MOVE IN 32 flex round trimless

MOVE IN 32 flex round

trimless

063-8211518S 063-8811117 002-90743

Quickinfo

3000 K
CRI ≥ 90 / 2 SDCM
68 lm/W, inset 91 lm/W
L80 / 50000 h
DALI-2
IP20

Colour

General

  • Ceiling
  • Semi-Recessed
  • tilt max 90°
  • rotation 360°
  • black
  • RAL9005 1
  • IP20
  • 800 lm

LED

  • 3000 K
  • CRI ≥ 90
  • L80 / 50000 h
  • initial MacAdam ≤ 2 SDCM
  • Rg: 100
  • Rf: 91
  • R{1-15}: 88
  • MR 0.59
  • MDER 0.53

Optical

  • spot
  • beam angle 18°
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • system 11.7 W
  • inset 8.7 W
  • 36 Vf
  • 250 mA
  • PC2 220-240V
  • system 68 lm/W3
  • inset 91 lm/W4
  • 1 DALI Addr.

Physical

  • trimless
  • diameter 63 mm
  • height 92 mm
  • 0.5 kg

Cutout

  • diameter 54 mm
  • min. ceiling thickness 9 mm
  • max. ceiling thickness 25 mm
  • recessed depth 110 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
C10
C13
C16
C20

Number of Fixtures

80
104
130
162
135
175
220
270
1 RAL code 2 Value of containing product at full load (undimmed) 3 incl. optical losses and the efficiency of the operating device (converter) 4 incl. optical losses

Round spotlight element in aluminium; surface black powder coated; installation without tools in mounting set due to patented ball catch system; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 9-25 mm; special mounting tool for easy installation of the trimless housing available as an accessory; spotlight element height adjustable without tools: flush with the ceiling, or extended 25 mm or 35 mm; 360° rotatable and 90° tiltable; passive cooling of the LEDs through improved heat sink geometry; with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows; light colour 3000 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; min. 80% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; high quality, aluminium, vapour deposition coated reflector with faceted lens design; precise radiation characteristic with 18° beam; good glare control through recessed light point level; optical attachment available as accessory; accessories are listed separately; degree of protection IP20; PC2 220-240V; incl. DALI-2 converter; converter wired secondary side; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;

Product data & specification documents

Datasheets

Planing files & lighting data

Download all
lightDistribution
lightDistribution
mainDrawing
