TUBO 60 CONEX surface / suspended system;TUBO 60 surface / suspended system;TUBO 60 CONEX plug / socket surface / suspended system;TUBO 60 CONEX socket / socket surface / suspended system

TUBO 60 CONEX plug / socket

surface / suspended system

058-3024537O

Quickinfo

3000 K
CRI ≥ 80 / 3 SDCM
114 lm/W
L90 / 50000 h
DALI-2
High Performance Opal
IP20 / PC1 / 220-240 V

Colour

General

  • Ceiling / Wall
  • Surface
  • white
  • RAL9010 1
  • 2700 lm/m
  • IP20
  • 3180 lm

LED

  • 3000 K
  • CRI ≥ 80
  • L90 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • MR 0.56
  • MDER 0.51

Optical

  • High Performance Opal
  • opal (lambertsch)
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • 220-240 V
  • system 27.9 W
  • PC1
  • system 114 lm/W3
  • 1 DALI Addr.
  • 24 W/m

Physical

  • length 1181 mm
  • width 60 mm
  • height 60 mm
  • 3.4 kg

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
C10
C13
C16
C20

Number of Fixtures

18
24
30
37
31
40
51
62
1 RAL code 2 Value of containing product at full load (undimmed) 3 incl. optical losses and the efficiency of the operating device (converter)

Carrier profile made of extruded aluminium profile; converter integrated into luminaire housing; for continuous lighting systems; surface white powder coated; for wall-/ceiling surface mounting or suspended mounting (1500 mm cable suspension - oblique or straight - as an accessory); easy installation using ceiling clips (available as an accessory) or with integrated toolless suspension height adjustment on the luminaire; freely positioned attachment to the luminaire; canopy for through wiring (available as an accessory); electrical connection of the luminaires via plug/socket system; connectors (L-, T- or X-shape) available as an accessory; luminaire connection rotatable around its own axis, which means that any spatial angle can be realized; light control via high quality lens system for maximum, homogeneous illumination; cylindrical cover made of satin PMMA for uniform illumination; with gentle ceiling illumination; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; degree of protection IP20; PC1; incl. DALI-2 converter; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
