TILA 16 adjustable
MOVE IT 10
030-6500436M
Quickinfo
2700 KCRI ≥ 90 / 3 SDCM
45 lm/W
L85 / 50000 h
DALI-2
IP20 / PC3 / 48 V
Colour
General
- Ceiling / Wall
- Track
- tilt max 135°
- rotation 365°
- brushed aluminium
- IP20
- 150 lm
LED
- 2700 K
- CRI ≥ 90
- L85 / 50000 h
- initial MacAdam ≤ 3 SDCM
- Rg: 99
- Rf: 91
- R{1-15}: 89
- MR 0.54
- MDER 0.49
Optical
- medium
- beam angle 23°
- ≤ 1.0 1
- SVM ≤ 0.4 1
Electrical
- DALI-2
- 48 V
- inset 3.3 W
- PC3
- inset 45 lm/W2
- 1 DALI Addr.
Physical
- diameter 16 mm
- height 80 mm
Decorative spotlight inset made of aluminium; surface lacquered in brushed aluminium; 365° rotatable and 135° tiltable; light inset can be installed and moved without tools by means of clip mount; power supplied via MOVE IT system track profile; hot plug protection; passive cooling of the LEDs through improved heat sink geometry; light colour 2700 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 85% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; good glare control through recessed light point level; high quality reflector; precise radiation characteristic with 23° beam; no multiple shadows; degree of protection IP20; PC3; DALI-2 control; flicker-free visual comfort through analogue current control (minimum value 1%); light source replaceable by an authorized professional;
