SETA 60 indirect surface / suspended system;SETA 60 indirect suspended system;SETA 60 CONEX indirect surface / suspended system;SETA 60 CONEX indirect suspended system;SETA 60 CONEX indirect plug / socket suspended system;SETA 60 CONEX indirect socket / socket suspended system

SETA 60 CONEX indirect socket / socket

suspended system

058-4238638

Quickinfo

4000 K
CRI ≥ 80 / 3 SDCM
UGR < 10 / 65° ≤ 1,500 cd/m²
158 lm/W
L90 / 50000 h
DALI-2
Reflector
IP20 / PC1 220-240V

Colour

General

  • Ceiling
  • Suspended
  • black
  • RAL9005 1
  • IP20
  • 7410 lm

LED

  • 4000 K
  • CRI ≥ 80
  • L90 / 50000 h
  • initial MacAdam ≤ 3 SDCM
  • MR 0.72
  • MDER 0.65

Optical

  • Reflector
  • symmetric
  • UGR < 10
  • ≥65° <1500 cd/m²
  • PstLM ≤ 1.0 2
  • SVM ≤ 0.4 2

Electrical

  • DALI-2
  • system 47 W
  • PC1 220-240V
  • system 158 lm/W3
  • 1 DALI Addr.

Physical

  • length 2351 mm
  • width 60 mm
  • height 60 mm

Circuit Breaker Types

Automatic Circuit Breaker Type

B10
B13
B16
B20
C10
C13
C16
C20

Number of Fixtures

31
40
50
62
52
67
85
104
1 RAL code 2 Value of containing product at full load (undimmed) 3 incl. optical losses and the efficiency of the operating device (converter)

Luminaire housing made of extruded aluminium profile; extremely slim design (only Ø 60 mm) linear; converter integrated into luminaire housing; for lighting systems; surface black powder coated; for suspended mounting (1500 mm cable suspension - oblique or straight - as an accessory); with integrated toolless suspension height adjustment on the luminaire; canopy for through wiring (available as an accessory); electrical connection of the luminaires via plug/socket system; connectors (L-, T- or X-shape) available as an accessory; luminaire connection rotatable around its own axis, which means that any spatial angle can be realized; extruded profile for improved thermal management; indirect light component with integrated PC boards and high quality lens system for maximum, homogeneous ceiling illumination; UGR ≤ 10; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 1500 cd/m²; light colour 4000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; degree of protection IP20; PC1 220-240V; incl. DALI-2 converter; accessories are listed separately; light source replaceable by an authorized professional; control gear replaceable by an authorized professional;
