PIVOT MOVE IT 25 / 25 S / 45 suspended

Technical data

General

Ceiling
Track Suspended
rotation 360°
black
RAL9005 ¹
1980 lm/m
IP20
1190 lm

LED

2700 K
CRI ≥ 80
L90 / 50000 h
initial MacAdam ≤ 3 SDCM
MR 0.47
MDER 0.42

Optical

opal (lambertsch)
$P_{st}^{LM}$ ≤ 1.0 ²
SVM ≤ 0.4 ²

Electrical

non DIM
48 V
inset 10.6 W
PC3
inset 112 lm/W³
18 W/m

Physical

length 610 mm
width 33 mm
height 33 mm
0.35 kg

^¹ RAL code ^² Value of containing product at full load (undimmed) ^³ incl. optical losses and the efficiency of the operating device (converter)

Specification text

Cylindrical, decorative-graphic light inset made of aluminium and satinised PMMA for homogeneous illumination; surface anodised black; light inset can be installed and moved without tools by means of magnetic holders+locking; pendant fitting with 1500mm cable suspension; suitable for two MOVE IT 25 / 25 S / 45 profiles as well as one MOVE IT 25 / 25 S / 45 profile (axial arrangement); holders 360° rotatable; power supplied via MOVE IT system track profile; hot plug protection; passive cooling of the LEDs through improved heat sink geometry; with CSP (Chip-Scale-Packaging) technology for maximum efficiency; light colour 2700 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 80; min. 90% of luminous flux after 50000 operating hours; energy efficient LEDs with high CRI; degree of protection IP20; PC3; non-dimmable; light source replaceable by an authorized professional;
