OPAL HIGH PERFORMANCE

MOVE IT 25 S

Quickinfo

2700 K, 3000 K, tunable white
CRI ≥ 90 / 3 SDCM
up to 90 lm/W
L80 / 50000 h, L85 / 50000 h
DALI-2 DT8 single control, DALI-2 single control, non DIM
High Performance Opal
IP20 / PC3 48V

Colour

    • Products and codes
    Discover family

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Linear light inset made of PMMA; light inset can be installed and moved without tools by means of magnetic holders+locking; flush with profile system (MOVE IT 25 S) or recessed luminaire level (MOVE IT 25); completely homogeneously illuminated, satinised PMMA cover; with CSP (Chip-Scale-Packaging) technology for maximum efficiency; energy-efficient LEDs with very good colour rendering; hot plug protection

    tunable white 1800 – 4000 K

    CRI ≥ 98 XPECTRUM (optional)

    Products and codes

    Filter
    75
    lm/W
    90
    lm/W
    238
    lm
    3460
    lm
    2.7
    W
    43
    W
    0.53
    0.76
    0.48
    0.69

    Colour

    • OPAL HIGH PERFORMANCE MOVE IT 25 S

    OPAL HIGH PERFORMANCE MOVE IT 25 S

    OPAL HIGH PERFORMANCE MOVE IT 25 S

    Status
    Article number(s)
    Type
    Dimming
    2700 K, system 5.3 W, 76 lm/W, length 305 mm
    non DIM
    2700 K, system 5.3 W, 76 lm/W, length 305 mm
    DALI-2 single control
    3000 K, system 5.3 W, 82 lm/W, length 305 mm
    non DIM
    3000 K, system 5.3 W, 82 lm/W, length 305 mm
    DALI-2 single control
    tunable white, system 2.7 W, 88 lm/W, length 305 mm
    DALI-2 DT8 single control
    2700 K, system 10.6 W, 76 lm/W, length 605 mm
    non DIM
    2700 K, system 10.6 W, 76 lm/W, length 605 mm
    DALI-2 single control
    3000 K, system 10.6 W, 82 lm/W, length 605 mm
    non DIM
    3000 K, system 10.6 W, 82 lm/W, length 605 mm
    DALI-2 single control
    tunable white, system 5.3 W, 90 lm/W, length 605 mm
    DALI-2 DT8 single control
    2700 K, system 21.3 W, 76 lm/W, length 1,205 mm
    non DIM
    2700 K, system 21.3 W, 76 lm/W, length 1,205 mm
    DALI-2 single control
    3000 K, system 21.3 W, 81 lm/W, length 1,205 mm
    non DIM
    3000 K, system 21.3 W, 81 lm/W, length 1,205 mm
    DALI-2 single control
    tunable white, system 10.6 W, 90 lm/W, length 1,205 mm
    DALI-2 DT8 single control
    2700 K, system 43 W, 75 lm/W, length 2,405 mm
    non DIM
    2700 K, system 43 W, 75 lm/W, length 2,405 mm
    DALI-2 single control
    3000 K, system 43 W, 80 lm/W, length 2,405 mm
    non DIM
    3000 K, system 43 W, 80 lm/W, length 2,405 mm
    DALI-2 single control
    tunable white, system 21.3 W, 90 lm/W, length 2,405 mm
    DALI-2 DT8 single control

    System products

    MOVE IT 25 S

    trimless system

    MOVE IT 25 S

    surface / suspended system

    MOVE IT 25 S

    suspended indirect system
