LENS WIDE MOVE IT PRO
LENS WALLWASHER MOVE IT PRO;LENS WIDE MOVE IT PRO
LENS WALLWASHER MOVE IT PRO;LENS WIDE MOVE IT PRO

LENS

MOVE IT PRO

New

Quickinfo

3000 K, 3500 K, 4000 K
CRI ≥ 80, CRI ≥ 90 / 3 SDCM
UGR < 19
up to 189 lm/W
L90 / 50000 h
DALI-2
IP20

Colour

    • Products and codes
    Discover family

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • ROLF
    • ULD

    Description

    Linear light inset made of plastic; light inset, incl. high power adapter + converter can be installed flexibly and without tools; flush with profile system; equipped with specially computed wide beam lenses; precise radiation characteristic with symmetrical light distribution; for use in schools and offices; energy-efficient LEDs with very good colour rendering

    DIN EN 12464-1 UGR ≤ 19

    up to 190 lm/W (high efficiency)

    Products and codes

    Filter
    134
    lm/W
    189
    lm/W
    2220
    lm
    8690
    lm
    16.6
    W
    46
    W
    0.56
    0.81
    0.51
    0.74

    Colour

    • LENS WIDE MOVE IT PRO

    LENS WIDE MOVE IT PRO

    LENS WIDE MOVE IT PRO

    Status
    Article number(s)
    Type
    Dimming
    3000 K, CRI ≥ CRI ≥ 90, 16.6 W, 134 lm/W, length 1,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 90, 16.6 W, 145 lm/W, length 1,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 90, 16.6 W, 134 lm/W, length 1,000 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 80, 16.6 W, 155 lm/W, length 1,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 80, 16.6 W, 175 lm/W, length 1,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 80, 16.6 W, 166 lm/W, length 1,000 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 90, 24.8 W, 134 lm/W, length 1,500 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 90, 24.8 W, 145 lm/W, length 1,500 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 90, 24.8 W, 134 lm/W, length 1,500 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 80, 24.8 W, 156 lm/W, length 1,500 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 80, 24.8 W, 175 lm/W, length 1,500 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 80, 24.8 W, 166 lm/W, length 1,500 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 90, 33 W, 135 lm/W, length 2,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 90, 33 W, 145 lm/W, length 2,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 90, 33 W, 135 lm/W, length 2,000 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 80, 33 W, 156 lm/W, length 2,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 80, 33 W, 176 lm/W, length 2,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 80, 33 W, 167 lm/W, length 2,000 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 90, 41 W, 135 lm/W, length 2,500 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 90, 41 W, 146 lm/W, length 2,500 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 90, 41 W, 135 lm/W, length 2,500 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 80, 41 W, 157 lm/W, length 2,500 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 80, 41 W, 177 lm/W, length 2,500 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 80, 41 W, 168 lm/W, length 2,500 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 90, 46 W, 145 lm/W, length 3,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 90, 46 W, 156 lm/W, length 3,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 90, 46 W, 145 lm/W, length 3,000 mm
    DALI-2
    3000 K, CRI ≥ CRI ≥ 80, 46 W, 168 lm/W, length 3,000 mm
    DALI-2
    4000 K, CRI ≥ CRI ≥ 80, 46 W, 189 lm/W, length 3,000 mm
    DALI-2
    3500 K, CRI ≥ CRI ≥ 80, 46 W, 179 lm/W, length 3,000 mm
    DALI-2
