MITA circle

suspended

Quickinfo

3000 K, 4000 K
CRI ≥ 80, CRI ≥ 90 / 3 SDCM
UGR < 13, UGR < 16, UGR < 19
up to ↓ 4,750 lm/↑ 4,380 lm
up to 160 lm/W
L90 / 50000 h
DALI-2
Opal, Reflector
IP20

Colour

white

black

Reflector

chrome

dark chrome

Products and codes

Discover family

Simple drawing

Light distribution

Downloads & links

Product data & specification documents

CataloguePage(s)

DWG - 2D

Download all

Aggregated downloads

DWG - 3D
Revit BIM data

Description

Ring shaped luminaire housing in die-cast aluminium; extremely slim design; surface powder coated; suspended; with height adjustable rod suspension (chrome), feed in rod; electronic operating unit installed in the canopy; optional: blind cover to cover the cut-out, held by magnet, available as an accessory; high gloss reflector with faceted design; HPO (High Performance Opal) cover for uniform illumination; either with direct or direct / indirect light distribution; energy-efficient LEDs with very good colour rendering

dark chrome reflector option

up to 139 lm/W (high efficiency)

version with opal cover

magnetic blind cover

DIN EN 12464-1 UGR ≤ 19

Products and codes

Filter

Colour

white

black

Reflector

chrome

dark chrome

MITA circle 450 opal direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 103 lm/W

DALI-2

black, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 112 lm/W

DALI-2

black, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 120 lm/W

DALI-2

black, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 137 lm/W

DALI-2

MITA circle 450 opal direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 103 lm/W

DALI-2

white, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 112 lm/W

DALI-2

white, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 120 lm/W

DALI-2

white, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 137 lm/W

DALI-2

MITA circle 450 opal direct suspended

Status

Article number(s)

Type

Dimming

black, 3000 K, CRI ≥ CRI ≥ 90, system 24.9 W, 96 lm/W

DALI-2

black, 4000 K, CRI ≥ CRI ≥ 90, system 24.9 W, 103 lm/W

DALI-2

black, 3000 K, CRI ≥ CRI ≥ 80, system 24.9 W, 111 lm/W

DALI-2

black, 4000 K, CRI ≥ CRI ≥ 80, system 24.9 W, 126 lm/W

DALI-2

MITA circle 450 opal direct suspended

Status

Article number(s)

Type

Dimming

white, 3000 K, CRI ≥ CRI ≥ 90, system 24.9 W, 96 lm/W

DALI-2

white, 4000 K, CRI ≥ CRI ≥ 90, system 24.9 W, 103 lm/W

DALI-2

white, 3000 K, CRI ≥ CRI ≥ 80, system 24.9 W, 111 lm/W

DALI-2

white, 4000 K, CRI ≥ CRI ≥ 80, system 24.9 W, 126 lm/W

DALI-2

MITA circle 450 reflector direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 115 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 124 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 134 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 152 lm/W

DALI-2

MITA circle 450 reflector direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 115 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 124 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 134 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 152 lm/W

DALI-2

MITA circle 450 reflector direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 98 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 106 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 114 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 129 lm/W

DALI-2

MITA circle 450 reflector direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 60 W, 98 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 60 W, 106 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 60 W, 114 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 60 W, 129 lm/W

DALI-2

MITA circle 450 reflector direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 30 W, 121 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 30 W, 131 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 30 W, 140 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 30 W, 160 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 40 W, 118 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 40 W, 128 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 40 W, 137 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 40 W, 156 lm/W

DALI-2

MITA circle 450 reflector direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 30 W, 121 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 30 W, 131 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 30 W, 140 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 30 W, 160 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 40 W, 118 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 40 W, 128 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 40 W, 137 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 40 W, 156 lm/W

DALI-2

MITA circle 450 reflector direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 30 W, 87 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 30 W, 93 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 30 W, 100 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 30 W, 114 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 40 W, 85 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 40 W, 91 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 40 W, 98 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 40 W, 112 lm/W

DALI-2

MITA circle 450 reflector direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 30 W, 87 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 30 W, 93 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 30 W, 100 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 30 W, 114 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 40 W, 85 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 40 W, 91 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 40 W, 98 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 40 W, 112 lm/W

DALI-2
