FRAME 40 high lumen trim, FRAME 40 mid lumen trim
FRAME 40 reflector trim
FRAME 40 reflector trim
FRAME 40 high lumen trim, FRAME 40 mid lumen trim
FRAME 40 reflector trim
FRAME 40 reflector trim
FRAME 40 high lumen trim, FRAME 40 mid lumen trim
FRAME 40 reflector trim
FRAME 40 reflector trim

FRAME 40

trim

Quickinfo

3000 K, 4000 K
CRI ≥ 90 / 3 SDCM
UGR < 16, UGR < 19
up to 3,260 lm/m
up to 142 lm/W
L90 / 50000 h
DALI-2
High Performance Opal, Microprismatic, Reflector
IP20

Colour

    • Reflector

    • Products and codes

    Simple drawing

    Light distribution

    Product data & specification documents

    Download all
    Download all
    • GLDF
    • 3DS
    • DWG - 3D
    • Revit BIM data

    Description

    Luminaire housing made of extruded aluminium; recessed luminaire with trim; suitable for ceiling thickness of 8-25 mm; surface powder coated; luminaire profile can be pre-mounted; remaining luminaire components mounted without tools; light inset consisting of highly reflective coated extruded profile for improved thermal management; HPO (High Performance Opal) cover for uniform illumination; micro prismatic PMMA diffuser incl. diffuser film for homogeneous illumination and reduced luminance; energy-efficient LEDs with very good colour rendering

    DiiA® standards 251, 252, 253

    system solution

    Products and codes

    Filter
    93
    lm/W
    142
    lm/W
    1200
    lm
    9510
    lm
    12.1
    W
    67
    W
    0.61
    0.81
    0.55
    0.74

    Colour

    • Reflector

    • FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 high lumen trim

    FRAME 40 high lumen trim

    Status
    Article number(s)
    Type
    Dimming
    black, High Performance Opal, 3000 K, 114 lm/W, length 1,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 100 lm/W, length 1,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 122 lm/W, length 1,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 108 lm/W, length 1,019 mm
    DALI-2
    black, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    black, High Performance Opal, 3000 K, 116 lm/W, length 3,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 103 lm/W, length 3,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 126 lm/W, length 3,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 111 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 high lumen trim

    FRAME 40 high lumen trim

    Status
    Article number(s)
    Type
    Dimming
    grey, High Performance Opal, 3000 K, 114 lm/W, length 1,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 100 lm/W, length 1,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 122 lm/W, length 1,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 108 lm/W, length 1,019 mm
    DALI-2
    grey, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    grey, High Performance Opal, 3000 K, 116 lm/W, length 3,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 103 lm/W, length 3,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 126 lm/W, length 3,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 111 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 high lumen trim

    FRAME 40 high lumen trim

    Status
    Article number(s)
    Type
    Dimming
    traffic white, High Performance Opal, 3000 K, 114 lm/W, length 1,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 100 lm/W, length 1,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 122 lm/W, length 1,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 108 lm/W, length 1,019 mm
    DALI-2
    traffic white, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    traffic white, High Performance Opal, 3000 K, 116 lm/W, length 3,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 103 lm/W, length 3,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 126 lm/W, length 3,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 111 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    Status
    Article number(s)
    Type
    Dimming
    black, High Performance Opal, 3000 K, 112 lm/W, length 1,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 99 lm/W, length 1,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 121 lm/W, length 1,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 107 lm/W, length 1,019 mm
    DALI-2
    black, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    black, High Performance Opal, 3000 K, 120 lm/W, length 3,019 mm
    DALI-2
    black, Microprismatic, 3000 K, 106 lm/W, length 3,019 mm
    DALI-2
    black, High Performance Opal, 4000 K, 130 lm/W, length 3,019 mm
    DALI-2
    black, Microprismatic, 4000 K, 114 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    Status
    Article number(s)
    Type
    Dimming
    grey, High Performance Opal, 3000 K, 112 lm/W, length 1,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 99 lm/W, length 1,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 121 lm/W, length 1,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 107 lm/W, length 1,019 mm
    DALI-2
    grey, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    grey, High Performance Opal, 3000 K, 120 lm/W, length 3,019 mm
    DALI-2
    grey, Microprismatic, 3000 K, 106 lm/W, length 3,019 mm
    DALI-2
    grey, High Performance Opal, 4000 K, 130 lm/W, length 3,019 mm
    DALI-2
    grey, Microprismatic, 4000 K, 114 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 high lumen trim, FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    FRAME 40 mid lumen trim

    Status
    Article number(s)
    Type
    Dimming
    traffic white, High Performance Opal, 3000 K, 112 lm/W, length 1,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 99 lm/W, length 1,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 121 lm/W, length 1,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 107 lm/W, length 1,019 mm
    DALI-2
    traffic white, High Performance Opal, 3000 K, 116 lm/W, length 2,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 103 lm/W, length 2,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 126 lm/W, length 2,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 111 lm/W, length 2,019 mm
    DALI-2
    traffic white, High Performance Opal, 3000 K, 120 lm/W, length 3,019 mm
    DALI-2
    traffic white, Microprismatic, 3000 K, 106 lm/W, length 3,019 mm
    DALI-2
    traffic white, High Performance Opal, 4000 K, 130 lm/W, length 3,019 mm
    DALI-2
    traffic white, Microprismatic, 4000 K, 114 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    black, Reflector chrome, Reflector, 3000 K, 125 lm/W, length 1,519 mm
    DALI-2
    black, Reflector chrome, Reflector, 4000 K, 136 lm/W, length 1,519 mm
    DALI-2
    black, Reflector chrome, Reflector, 3000 K, 128 lm/W, length 2,019 mm
    DALI-2
    black, Reflector chrome, Reflector, 4000 K, 138 lm/W, length 2,019 mm
    DALI-2
    black, Reflector chrome, Reflector, 3000 K, 131 lm/W, length 3,019 mm
    DALI-2
    black, Reflector chrome, Reflector, 4000 K, 142 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    grey, Reflector chrome, Reflector, 3000 K, 125 lm/W, length 1,519 mm
    DALI-2
    grey, Reflector chrome, Reflector, 4000 K, 136 lm/W, length 1,519 mm
    DALI-2
    grey, Reflector chrome, Reflector, 3000 K, 128 lm/W, length 2,019 mm
    DALI-2
    grey, Reflector chrome, Reflector, 4000 K, 138 lm/W, length 2,019 mm
    DALI-2
    grey, Reflector chrome, Reflector, 3000 K, 131 lm/W, length 3,019 mm
    DALI-2
    grey, Reflector chrome, Reflector, 4000 K, 142 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    traffic white, Reflector chrome, Reflector, 3000 K, 125 lm/W, length 1,519 mm
    DALI-2
    traffic white, Reflector chrome, Reflector, 4000 K, 136 lm/W, length 1,519 mm
    DALI-2
    traffic white, Reflector chrome, Reflector, 3000 K, 128 lm/W, length 2,019 mm
    DALI-2
    traffic white, Reflector chrome, Reflector, 4000 K, 138 lm/W, length 2,019 mm
    DALI-2
    traffic white, Reflector chrome, Reflector, 3000 K, 131 lm/W, length 3,019 mm
    DALI-2
    traffic white, Reflector chrome, Reflector, 4000 K, 142 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    black, Reflector dark chrome, Reflector, 3000 K, 93 lm/W, length 1,519 mm
    DALI-2
    black, Reflector dark chrome, Reflector, 4000 K, 101 lm/W, length 1,519 mm
    DALI-2
    black, Reflector dark chrome, Reflector, 3000 K, 95 lm/W, length 2,019 mm
    DALI-2
    black, Reflector dark chrome, Reflector, 4000 K, 103 lm/W, length 2,019 mm
    DALI-2
    black, Reflector dark chrome, Reflector, 3000 K, 98 lm/W, length 3,019 mm
    DALI-2
    black, Reflector dark chrome, Reflector, 4000 K, 106 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    grey, Reflector dark chrome, Reflector, 3000 K, 93 lm/W, length 1,519 mm
    DALI-2
    grey, Reflector dark chrome, Reflector, 4000 K, 101 lm/W, length 1,519 mm
    DALI-2
    grey, Reflector dark chrome, Reflector, 3000 K, 95 lm/W, length 2,019 mm
    DALI-2
    grey, Reflector dark chrome, Reflector, 4000 K, 103 lm/W, length 2,019 mm
    DALI-2
    grey, Reflector dark chrome, Reflector, 3000 K, 98 lm/W, length 3,019 mm
    DALI-2
    grey, Reflector dark chrome, Reflector, 4000 K, 106 lm/W, length 3,019 mm
    DALI-2
    FRAME 40 reflector trim

    FRAME 40 reflector trim

    FRAME 40 reflector trim

    Status
    Article number(s)
    Type
    Dimming
    traffic white, Reflector dark chrome, Reflector, 3000 K, 93 lm/W, length 1,519 mm
    DALI-2
    traffic white, Reflector dark chrome, Reflector, 4000 K, 101 lm/W, length 1,519 mm
    DALI-2
    traffic white, Reflector dark chrome, Reflector, 3000 K, 95 lm/W, length 2,019 mm
    DALI-2
    traffic white, Reflector dark chrome, Reflector, 4000 K, 103 lm/W, length 2,019 mm
    DALI-2
    traffic white, Reflector dark chrome, Reflector, 3000 K, 98 lm/W, length 3,019 mm
    DALI-2
    traffic white, Reflector dark chrome, Reflector, 4000 K, 106 lm/W, length 3,019 mm
    DALI-2
