BETO circle

suspended

Quickinfo

3000 K, 4000 K, tunable white
CRI ≥ 80, CRI ≥ 90 / 3 SDCM
UGR < 10, UGR < 13, UGR < 16, UGR < 19
up to ↓ 14,600 lm/↑ 13,900 lm
up to 166 lm/W
L90 / 50000 h
DALI-2, DALI-2 D/I separately controllable
Reflector
IP20

Colour

white

black

Reflector

chrome

dark chrome

Products and codes

Discover family

Simple drawing

Light distribution

Downloads & links

Product data & specification documents

CataloguePage(s)

DWG - 2D

Download all

Aggregated downloads

IES
LDT
ROLF
ULD

3DS
DWG - 3D
Revit BIM data

Description

Ring shaped luminaire housing from rolled aluminium extruded profile, seamlessly welded; extremely slim design (only 42 x 42 mm); surface powder coated; pendant fitting with cable suspension; height adjustment without tools; incl. transparent feed; electronic operating unit installed in the canopy; extruded profile for improved thermal management; high-gloss reflector with faceted design; direct or direct / indirect light distribution; indirect light component with integrated PC boards and high-quality lens system for maximum, homogeneous ceiling illumination; energy-efficient LEDs with very good colour rendering

DIN EN 12464-1 UGR ≤ 19

CRI ≥ 98 XPECTRUM (optional)

Products and codes

Filter

Colour

white

black

Reflector

chrome

dark chrome

BETO circle 800 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 92 W, 118 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 92 W, 127 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 92 W, 137 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 92 W, 156 lm/W

DALI-2

black, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 126 lm/W

DALI-2

BETO circle 800 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 92 W, 118 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 92 W, 127 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 92 W, 137 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 92 W, 156 lm/W

DALI-2

white, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 126 lm/W

DALI-2

BETO circle 800 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 92 W, 103 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 92 W, 111 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 92 W, 120 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 92 W, 136 lm/W

DALI-2

black, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 107 lm/W

DALI-2

BETO circle 800 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 92 W, 103 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 92 W, 111 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 92 W, 120 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 92 W, 136 lm/W

DALI-2

white, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 107 lm/W

DALI-2

BETO circle 800 direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 46 W, 120 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 46 W, 130 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 46 W, 139 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 46 W, 158 lm/W

DALI-2

black, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 50 W, 117 lm/W

DALI-2

BETO circle 800 direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 46 W, 120 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 46 W, 130 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 46 W, 139 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 46 W, 158 lm/W

DALI-2

white, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 50 W, 117 lm/W

DALI-2

BETO circle 800 direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 46 W, 86 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 46 W, 93 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 46 W, 100 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 46 W, 113 lm/W

DALI-2

black, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 50 W, 84 lm/W

DALI-2

BETO circle 800 direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 46 W, 86 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 46 W, 93 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 46 W, 100 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 46 W, 113 lm/W

DALI-2

white, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 50 W, 84 lm/W

DALI-2

BETO circle 1600 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 172 W, 126 lm/W

DALI-2 D/I separately controllable

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 172 W, 135 lm/W

DALI-2 D/I separately controllable

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 172 W, 145 lm/W

DALI-2 D/I separately controllable

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 172 W, 166 lm/W

DALI-2 D/I separately controllable

BETO circle 1600 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 172 W, 126 lm/W

DALI-2 D/I separately controllable

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 172 W, 135 lm/W

DALI-2 D/I separately controllable

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 172 W, 145 lm/W

DALI-2 D/I separately controllable

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 172 W, 166 lm/W

DALI-2 D/I separately controllable

BETO circle 1600 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 172 W, 107 lm/W

DALI-2 D/I separately controllable

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 172 W, 115 lm/W

DALI-2 D/I separately controllable

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 172 W, 124 lm/W

DALI-2 D/I separately controllable

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 172 W, 141 lm/W

DALI-2 D/I separately controllable

BETO circle 1600 direct / indirect power suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 172 W, 107 lm/W

DALI-2 D/I separately controllable

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 172 W, 115 lm/W

DALI-2 D/I separately controllable

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 172 W, 124 lm/W

DALI-2 D/I separately controllable

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 172 W, 141 lm/W

DALI-2 D/I separately controllable

BETO circle 1600 direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 91 W, 122 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 91 W, 131 lm/W

DALI-2

black, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 91 W, 141 lm/W

DALI-2

black, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 91 W, 160 lm/W

DALI-2

black, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 124 lm/W

DALI-2

BETO circle 1600 direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 90, system 91 W, 122 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 90, system 91 W, 131 lm/W

DALI-2

white, Reflector chrome, 3000 K, CRI ≥ CRI ≥ 80, system 91 W, 141 lm/W

DALI-2

white, Reflector chrome, 4000 K, CRI ≥ CRI ≥ 80, system 91 W, 160 lm/W

DALI-2

white, Reflector chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 124 lm/W

DALI-2

BETO circle 1600 direct suspended

Status

Article number(s)

Type

Dimming

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 91 W, 87 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 91 W, 94 lm/W

DALI-2

black, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 91 W, 101 lm/W

DALI-2

black, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 91 W, 114 lm/W

DALI-2

black, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 89 lm/W

DALI-2

BETO circle 1600 direct suspended

Status

Article number(s)

Type

Dimming

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 90, system 91 W, 87 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 90, system 91 W, 94 lm/W

DALI-2

white, Reflector dark chrome, 3000 K, CRI ≥ CRI ≥ 80, system 91 W, 101 lm/W

DALI-2

white, Reflector dark chrome, 4000 K, CRI ≥ CRI ≥ 80, system 91 W, 114 lm/W

DALI-2

white, Reflector dark chrome, tunable white, CRI ≥ CRI ≥ 90, system 94 W, 89 lm/W

DALI-2
