MOUNTING HOUSING 300 trim linear
049-8853037
Colour
General
- Ceiling
- Recessed
- traffic white
- RAL 9016 1
- IP20
Electrical
- DALI-2
- PC1 220-240V
- 1 DALI Addr.
Physical
- length 344 mm
- width 254 mm
- height 120 mm
Cutout
- length 335 mm
- width 135 mm
- min. ceiling thickness 12.5 mm
- max. ceiling thickness 12.5 mm
- recessed depth 175 mm
1 RAL code
Installation housing in pressed steel sheet with rectangular cut-out; with wrap around edge; suitable for ceiling thickness of 12.5 mm; 3 non-reversible plug and play connector sockets for power supply to the spotlights; spotlight can be installed and moved without tools by means of magnetic holders; hot plug protection; surface traffic white powder coated; degree of protection IP20; PC1 220-240V; incl. DALI-2 converter; all spotlights together DALI dimmable; control gear replaceable by an authorized professional;
