MINO CIRCLE ACOUSTIC 1000 ceiling;MINO CIRCLE ACOUSTIC 1000 inlay

MINO CIRCLE ACOUSTIC 1000

inlay

034-270111W

Quickinfo

PET felt
from recycled material
up to absorption class A
flame retardant version available

Colour

General

  • Luminaire / Track
  • Mounted
  • white

Physical

  • diameter 937 mm
  • height 24 mm
  • 2.09 kg

Acoustics

  • Alpha w (αw) up to 0.65 1
  • SAC (sound absorption class) up to C 1
  • NRC up to 0.7 1
  • SAA up to 0.74 1

Equivalent sound absorption area (Aeq)

125 Hz

0.5

250 Hz

0.5

500 Hz

0.87

1000 Hz

1.3

2000 Hz

1.43

4000 Hz

1.57
1 Alpha w, SAC, NRC, SAA refer to the best result of the entire product family

Acoustic element made of high quality, self-supporting PET felt with sound absorbing properties, consisting of 50% recycled PET; round design; high quality visual and tactile surface, white; colour may deviate; absorption of direct sound and sound reflected from the ceiling; this creates high acoustic performance; for insertion into the MINO 60 CIRCLE 1000 ceiling or MINO 60 CIRCLE 1000 suspended;

Product data & specification documents

Datasheets

Certificates

Download all
mainDrawing

Used in products
