INO 900 circle acoustic
luminaire mounted
034-370311W
Quickinfo
PET feltflame retardant version available
Colour
General
- Luminaire / Track
- Mounted
- white
Physical
- diameter 794 mm
- height 9 mm
- 0.84 kg
Acoustics
- Alpha w (αw) up to 0.6
- SAC (sound absorption class) up to C
- NRC up to 0.55
- SAA up to 0.57
- Acoustic data calculations based on INO CIRCLE ACOUSTIC 700 circle, cavity 100cm
Equivalent sound absorption area (Aeq)
125 Hz
0.3
250 Hz
0.27
500 Hz
0.47
1000 Hz
0.53
2000 Hz
0.63
4000 Hz
0.8
Acoustic element made of high quality, self-supporting PET felt with sound absorbing properties, consisting of at least 50% post-consumer recycled PET; round design; high quality visual and tactile surface, white; colour may deviate; for mounting on the INO circle suspended cable suspensions, above the luminaire; subsequent attachment possible;
